1. Trimming Scrub after drilling (Deburring Scrub)

Metal pre-treatment scrubbing. Surface Scrubbing for trimming after drilling and enhance plate adhesion

Line Configuration 4 - Spindle Buff Scrubbing Machine + High Pressure Washer + Water Rinse and Dryer Unit
Ancillary Copper Powder Collection Filter

To reduce the occurrence of excessive copper powder on the area around the hole of the surface.
Brush may be used to prevent hole clogging of buff scraps and other hole clogging.

  MDS-704S
MDS-604SSC


2. Pre-scrubbing for Dry film operation

Scrub to obtain optimum surface roughness for adhesion of Dry film.

Line Configuration 4 - Spindle Buff Scrubbing Machine + Water rinse + Soft Etching + Water Rinse and Dryer Unit
Ancillary Chemicals Management System, Copper Powder Collection Filter

Acid washing may be inserted prior to scrubbing. The efficiency of etching will be varied according to the chemical manufacturers.

  MDS-604FB
MDS-704S
MDS-604SSC


3. Solder Resist Process

Perform surface cleaning and conditioning after pattern formation. This is a scrubbing process to enhance adhesion of resist ink.

Line Configuration 4-Spindle (2-spindle) Buff Scrubbing Machine + Washer + Soft Etching + Water Rinse and Dryer Unit
Line Configuration Copper Powder Collection Filter

It is essential to select Buff with great care and attention to prevent from occurrence of disconnection or short out between individual patterns after pattern formation.

  MDS-604FB
MDS-704S
MDS-604SSC


4. SUS Board Scrub

Surface scrubbing of SUS board for pressing multi-layer board

Line Configuration 4 - spindle buff Scrubbing Machine + Water Rinse and Dryer Unit
Ancillary Copper Powder Collection Filter

Amount of resin adhere to SUS board is varied according to processing method. Resins around pin hole should be removed in the preceding processes. Also, require careful attention with specification of dry part to prevent from getting water stain.

  MDS-604FB


5. Removing Padding Ink

5-1 Surface of IVH Resin Removal (Through-Hole Protection)

Line Configuration 6-spindle scrubbing machine + Water Rinse and Dryer Unit
Ancillary Copper Powder Collection Filter
  MDS-604FB


5.2 Removal of padding resin before forming circuit
Removal of padding resin after circuit is formed

Line Configuration 8-spindle Scrubbing Machine or 10-spindle Scrubbing Machine + Water Rinse and Dryer Unit
Ancillary Copper Powder Collection Filter

Permanent padding (copper pastes) scrubbing of 0.1t board is the most difficult task in scrubbing process. ?We have proprietary technical know-how on such scrubbing process to prevent from rolling of the board.

  MDS-604FB MDS-604FB


  MDS-604FB MDS-604FB


6. Special Scrubbing Application

6-1 Flexible Board ?Super-thin plate (Max. total thickness 60 micron)

Line Configuration Vibration Sander Scrub + Over-turn machine + Vibration Sander Scrub

This is the one of state-of-the-art scrubbing machine developed by us, ideal for scrubbing roughened surface after the plate processing.

  MVS-602B MVS-602B


6-2 Thickness Correction or Padding Ink Removal

Line Configuration Belt-type Scrubbing Machine + Over-turn machine + Belt-type Scrubbing Machine + Water Rinse and Dryer Unit

This can be used for correcting thickness of board after the plate processing. It enables to scrub around 3 micron-per -path. Such scrubbing equipment would commonly be used where have a poor condition of plating process.

MNW-610-C2
MNW-710-C2



Inquiry
Option
Copper Powder Recovery Machine
F2 Filter
Model
F2-103 / F2-203 / NF2W Produced by Touei Aqua-tech Co., Ltd.


Consumable Goods
Scrubbing Application
For deburring scrubbing before plate processing / deburring around holes
Spiral Cutter
Spiral Cutter
Produced by
KURE GRINDING WHEEL Co.,Ltd.
http://www.kgw.co.jp/l
Super Grid
Super Grid
Produced by Tsunoda Bursh Co., Ltd
http://www.tsunoda-brush.co.jp
Resin Cloth Product / Cork Product for Belt Sander
Resin Cloth Product / Cork Product for Belt Sander
Produced by Sankyo-rikagaku.co., ltd
http://sankyorikagaku.co.jp
スパイラルカッター
Fine Super pellet
Nihon Kenshi Co., Ltd.
http://www.nihonkenshi.co.jp
スパイラルカッター
Hi-Cut buff


Inquiry
Service

For keeping up higher level of performance of machinery, we provide regular maintenance service such as replacement of parts and precision adjustment in machine. Our member of staff will visit your premise and carry out maintenance check up by arrangement beforehand.
Partial maintenance on-demand, such as main spindle part, back-up roller and conveyor unit, etc will be variable to meet individual requirement by arrangement in advance.
We also, offer Marugen produced equipment parts as well as bought-in parts.


Inquiry
